Rated working voltageAC230V 50HZProduct protection gradelP20Leakage protection setting value30mAOver-voltage protection265VOver temperature protection75°CShort circuit protection0.01sWater immersion protection60S trip protectionsetting after water immersionShellframe current100AOperating ambient temperature-25~70°CRated current32A/63A/100A(optional)Undervoltage protecti...
Short circuit protection
Immersion to prevent electric shock
Overvoltage and undervoltage protection
surge resistance
Leakage protection
LED display
Overcurrent protection
Over Temperature Protection
Phase loss protection
Rated working voltage | AC230V 50HZ |
Product protection grade | lP20 |
Leakage protection setting value | 30mA |
Over-voltage protection | 265V |
Over temperature protection | 75°C |
Short circuit protection | 0.01s |
Water immersion protection | 60S trip protectionsetting after water immersion |
Shellframe current | 100A |
Operating ambient temperature | -25~70°C |
Rated current | 32A/63A/100A(optional) |
Undervoltage protection | 180V |
Leakage protection action | 0.1s |
Communication mode | RS485 |
Rated operating short circuit breaking capacity lcs(A) | lcs=lcu=6000A |
